妙用与介绍/Brief Introduction：

该线由美式挤出机螺杆洗瓶吹干一体式机、口服药液装罐轧盖机二台电脑单人组建，可分成清洁、干燥处理高压蒸汽高压蒸汽灭菌和装罐封好4个业务区，全部可对接加工，也可电脑单人实用。可做好淋水、超声心动图波清洁、冲水、冲气、吹干高压蒸汽高压蒸汽灭菌、加热、装罐、理盖、戴盖、轧盖等生产工序。The line is made up of two single machine, one straight-line screw bottle washing and drying machine and one oral liquid filling and capping machine. The line is divided into cleaning, drying, sterilization and filling sealing three workspace, all can joint production, also can use single. It can complete water spray, ultrasonic cleaning, water flushing, air flushing, drying sterilization, cooling, filling, cap arranging, capping, sealing, etc.

优缺点/Characteristic：

使用超超声波的洗涤及气水间歇性洗、远红外高温天气消毒、双头装灌与粘口等技术工艺。整线三级联动系统自动抑制。运作简洁明了以便于，做到了机电专业成融合。Using ultrasonic cleaning and water washing alternately, far-infrared high-temperature sterilization, such as long filling and sealing technology. The automatic control of the whole line linkage. Simple and convenient operation, electromechanical integration is realized.

的技术性能参数/ Technical Parameters：

生产能力technical parameters	80-150瓶/分80-150 bottles/min
适宜规格尺寸 Cutting dimension	5-20ml
电  容  量Amount of electric capacity	65Kw(在这其中常规任务36Kw)(including normal workinღg 36 kw)
机器设备毛重machine net weight	6800Kg
外形尺寸boundary dimension	9650×2360×1900mm（长×宽×高）(length x width x height)
