的用途与详细资料/Brief Introduction：

机器是你有限公司在获取在美国发达技术工艺的知识基础上新产品开发的，广泛的用于喷雾器剂装灌设备线的专属系统。采用很多木头材质方形、怪型瓶，很多规格尺寸喷咀的装灌设备线旋（轧）盖。装饰管柱塞泵按量装灌设备线、气动弹簧上盖、起降式旋盖。拥有装灌设备线计算准确的、旋盖平稳性、方法简单等优越性。长期处在中国内地世界领先作用。广泛的应广泛的用于医疗器械、日化用品等互联网行业。The machine is special purpose for filling spray. It’s fit for all kinds of bottles of materials and shapes ,This machine is available for series of round and flat bottles. It adopts stainless piston measuring pump for filling, pneumatic capping, and rising-and-falling screwing. The machine enjoys advantages of accurate measurement, stable screwing and easy operation,widely used in pharmaceuticals and cosmetic industry

优缺点/Characteristic：

◆全部的电嚣电子器件均用到老牌企业。滤油机运营直观性 便利，无瓶不装罐，检定*，无瓶不上盖。All elements is well know brand. Direct viewing operation, no bottle no filling, measuring accurate, no bottle no capping.◆上盖手机定位装置设备，以确保打印机喷头塑料件管较长或弯度时能否较准渗入瓶口。Cap adding device, ensure pipe of cap into mouth of bottle easy even it’s long or crooked。◆ 齐全遵照GMP原则做成。The whole machine is designed according to the requirements of GMP.

的技术数据/Technical Parameters：

适用性规格尺寸Filling Volume	5-500ml
工作效果Productivity	30-50瓶/分   60-100瓶/分 30-50bottles/min  60-100bottles/min
灌装生产线定位精度Filling Precision	≤±1%
电源开关Plugging ratio	380V/50Hz
上盖率 Air Supply	≥98%
气动阀门Power Supply	1.5M3/小时候 0.4-0.7Mpa
电功率Power	1.5 kw
器机总重量 Weight	500 kg
外型长度Dimension	2000*1000*1500mm
