使用用途与简绍/Brief Introduction：

全系统系统半自动轴向柱塞泵泵式膏体酱分电脑装机是品牌转变互联网行业市场标准发掘的新新产品上市。机械运用SUS304304不绣钢轴向柱塞泵泵式记量泵施行分装，且集系统系统半自动上盖、系统系统半自动旋盖、机械设备高压电器为分立式，经济条件软件应用，占地表积大小小，很广软件应用于医药化工、调味品、药剂、医药化工、美妆品等互联网行业的药液包装机，满足GMP规范了规范。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

亮点/characteristic：

◆选择柱塞泵式量值溯源泵强制执行灌装生产线，实用一些浓稠度粘液，gps精高；泵的形式选择快接式拆下来结构，更加方便清洁、消毒液。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆轴向柱塞泵式计量检验泵活塞件环金属原料依据相关行业及溶剂物质的各不相同适用硅橡塑，四氟丁二烯或同一金属原料，特殊性时候适用瓷器金属原料。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC调整系统，直流变频空调可控硅调压，半自动化控制层面高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不灌装设备，主动运算功能模块。Lack of bottle filling, automatic counting function◆装量采取调节更方便，可是次采取调节任何的的计量泵的充填量，也可重视以及的的计量泵采取微幅采取调节；进行操作简便方法，采取调节很快。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆包装针头不设防漏滴设备，充填时闯进瓶底包装，慢提高，制止导致气泡。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆整体可实用有差异 样式的塑料瓶，更改简约，可在短期间内达成。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆组装机按GMP要的设计。The machine designed according to the requirements of GMP

技艺数据/technic parameter：

可用空瓶标准Size of bottles	20-1000ml（通过规定订制）20-1000 - ml (according to your need）
选用可乐瓶尺寸Apply the bottle diameter	¢20-¢150mm
可用于盖子外形尺寸Apply the lid specifications	¢20-¢70mm
生产方式工作能力 production capacity	四头灌装生产线：1000-2500瓶/钟头 Four filling head: 1000-2500 bottles per hour 八头装灌：2500-4000瓶/小的时候 Eight head filling: 2500-4000 bottles per hour 12头灌装生产线：4000-6000瓶/小 12 head filling: 4000-6000 bottles per hour
装量数据误差The load error	±1%
旋盖合适率Screw cover percent of pass	≥99%
外接电源power supply	380V，50HZ
工作功率power	3.0KW
气动阀门gas sources	0.4-0.75MPA
强度掌控speed control	调频调压variable speed
